Rated capacity	±50 N?m ~ ±3 kN?m
Safe overload	150 %R.C.
Ultimate overload	300 %R.C.
Rated output	0 V ~ ±10 V0 V ~ ±5 V 4-20mA 5-15kHz 485 CAN
Accuracy of detected value	Digital : ±0.5 %R.O., Analog : ±0.25%R.O.±0.1%R.O. (including linearity, hysteresis and repeatablity.)
Maximum rotation speed	RK-700100NM ~ -300NM : 5 000 rpm RK-700-500NM, -1KNM :4000 rpm RK-700-2KNM, -3KNM : 35 00 rpm
Temp. range, safe	-10 ℃ ~ 70 ℃
Temp. range, compensated	0 ℃ ~ 60 ℃
Temp. effect on zero balance	0.02 %R.O./10 ℃
Temp. effect on output	0.03 %LOAD/10 ℃
Zero shift by rotation	0.5 %R.O.p-p (at WB＝1 kHz)
Mechanical characteristics	100NM	200NM	300NM	500NM	1kNM	2KNM	3KNM
Torsional peculiar pitch (kHz)	5.357	5.778	6.577	6.413	6.274	4.040	4.508
Bending peculiar pitch
Radial direction (kHz)	3.375	3.497	3.763	3.919	4.016	2.151	2.368
Thrust direction (kHz)	3.966	4.065	4.284	4.404	4.988	2.672	2.844
Twist angle at rated capacity (°)	0.015	0.027	0.031	0.037	0.049	0.067	0.082
Accuracy safe bending load (N)	75	150	225	375	750	800	1 000
Accuracy safe thrust load (N)	65	130	195	325	650	3 750	12 000
Class of protection	IP54
Material	Rotor part : Alloy steel, Stator part : Alluminium alloy

1) Each type of irregular stress can only be permitted with its given limit value (bending moment, side load or axial load, exceeding the nominal
speed) if none of the others can occur. Otherwise the limit values must be reduced. If for instance 30 % of the bending moment and also 30 %
of the side load are present, only 40 % of the axial load are permitted, provided that the nominal torque is not exceeded. With maximum addi-
tional loading, measuring errors of the order of 1 % of the nominal torque can occur.
2) The nominal torque must not then be exceeded.
